Descriptif
4-MP 1/3" CMOS image sensor, excellent low luminance performance and high definition of images. Outputs max. 4 MP (2688 × 1520) 25/30 fps. H.265 codec, high compression rate, ultra-low bit rate. Built-in IR LED, max. IR distance: 50 m. ROI, SMART H.264 et/H.265et, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments. Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human). Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection. Alarm: 1 in, 1 out (Only - AS supports), audio: 1 in, 1 out (Only - AS supports), max. 256 G Micro SD card. built-in Mic. 12 VDC/PoE power supply facilitates installation. IP67 protection. SMD 4.0, AI SSA.
Caractéristiques
-
Objectif fixe : 2.8mm
-
Capteur 1/2.9'' CMOS
-
Résolution maximale : 4MP
-
Distance infrarouge : 50 mètres
-
Fonction d'amélioration d'image : · Rotation mode, WDR (120dB), 3D NR, HLC, BLC
-
Alimentation DC12V, PoE (802.3af), max. 3.8W, 4.6W
-
Panoramique : 0°–360° ; Inclinaison : 0° à 90° ; Rotation : 0° à 360°
-
Angle de vue : Horizontal : 107° ; vertical : 56° ; diagonale : 127°
-
IP67
-
25/30 fps@4MP (2688x1520)
-
Compression vidéo H.265/H.264B/H.264/H.264H
-
Illumination minimale 0.005 lux@F1.4
-
Détection analyse intelligente : intrusion dans zone, franchissement de ligne
-
3 flux
-
Compatibilité ONVIF (Profile S/G/T), CGI
-
1 RJ45 (10/100 Base-T)
-
Port carte micro SD, max. 256GB
-
Température de fonctionnement -40°C à 60°C
-
Dimensions : 19.2cm x 7.05cm x 6.6cm
-
Poids : 590g
