Descriptif
sup. à 5-MP 1/2.7" CMOS image sensor, excellent low luminance performance and high definition of images. sup. à Outputs max. 5 MP (2960 × 1668) 20 fps and supports 4MP (2688 × 1520) 25/30 fps. sup. à H.265 codec, high compression rate, ultra-low bit rate. sup. à Built-in IR LED, max. IR distance: 50 m. sup. à ROI, SMART H.264 et/H.265et, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments. sup. à Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. sup. à Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human). sup. à Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection. sup. à Alarm: 1 in, 1 out (Only - AS supports), audio: 1 in, 1 out (Only - AS supports), max. 256 G Micro SD card. built-in Mic. sup. à 12 VDC/PoE power supply, easy for installation. sup. à IP67 protection. sup. à SMD 4.0, AI SSA.
Caractéristiques
-
Objectif fixe : 2.8mm
-
Capteur 1/2.7'' CMOS
-
Résolution maximale : 5MP
-
Distance infrarouge : 50 mètres
-
Fonction d'amélioration d'image : Rotation d’image, WDR, 3D DNR, HLC, BLC, filigrane numérique, applicable à diverses scènes
-
Alimentation 12 V CD, PoE (802.3af), max. 5.3W, max. 6.5W
-
IP67
-
20fps@5MP(2960x1668)
-
Compression vidéo H.265/H.264/H.264B/MJPEG
-
Illumination minimale 0.005 Lux@F1.4 (couleur, 30 IRE), 0.0005 Lux@F1.4(Noir/blanc, 30 IRE)
-
Fonctions intelligentes : franchissement de ligne, détection d'intrusion
-
Pan : 0°~360°, Tilt : 0°~90°, Rotation : 0°~360°
-
Angle de vue : H : 111°, V : 58°, D: 132°
-
Port carte SD, max. 256GB
-
Micro intégré
-
Alarme I/O 1/1, Audio I/ 1/1
-
RJ-45 (10/100 Base-T)
-
Compatibilité : ONVIF (profil S/G/T), CGI, P2P, Jalon, Genetec
-
Température de fonctionnement -40°C à 60°C
-
Dimensions : 19.2cm x 7.05cm x 6.6cm
-
Poids : 590g
